Huawei c662d-z23 02352rcb 2 million star level infrared spherical camera
Product features
Support extra265 encoding format, support dual independent 1080p HD encoding
? 1080p@60fps High frame rate, smoother video image
Strong light suppression, no loss of key information under strong light interference
120dB super wide dynamic, strong contrast scene, real restore details
Intelligent fog penetration to enhance image clarity in foggy scenes
Intelligent extraction of metadata to provide massive metadata for Intelligent Applications
Code stream package, typical scene configuration package and planned tasks
Powerful sec error correction, 20% network packet loss image is still smooth
Active automatic demisting to prevent the inner part of the shield from fogging
Quick installation structure, more efficient installation and deployment
Huawei c662d-z23 image sensor: 1 / 2.7 "2 megapixel progressive scan CMOS; Maximum resolution: 1920 × 1080; Minimum illumination: Color: 0.005lux, black and white: 0.0005lux; Focal length: 5-115mm; Optical zoom ratio: 23; Horizontal rotation range: 0 °～ three hundred and sixty °; Vertical rotation range: - 15 °～ ninety °; Fill light: 150m; Compression coding: h.265/h.264/mjpeg; Behavior analysis: support; Exception detection: support; 3D positioning: -; Intelligent tracking: support; Power supply: AC24 V, Poe + (IEEE 802.3 at); Working temperature: - 30 ℃ ~ 60 ℃; Protection / riot / lightning protection: IP66, 6kV; 02352rcb fastball 1790-2685 02352rcb c662d-z23
Product model: c662d-z23
video camera
Image sensor: 1 / 2.7 "2 megapixel progressive scan CMOS
Effective image size: 1920 (H) × 1080(V)
Minimum illumination:
Color: 0.005lux (f1.2, AGC on, 1 / 30 shutter)
Black and white: 0.0005lux (f1.2, AGC on, 1 / 30 shutter)
Day and night mode: automatic / color / black and white (ICR infrared cut-off filter)
Shutter speed: 1 / 3S ~ 1 / 68250s
Wide dynamic range: 120dB
Gain control: automatic / manual
White balance: Auto Tracking / Auto / manual
Strong light suppression: support
Image fogging: Auto / manual / off
Video anti shake: support
Day and night focus compensation: support
Lens & fill
Focal length: 5-115mm
Zoom: 23x optical zoom
Maximum aperture: f1.55
Aperture type: p-iris
Light compensation distance: 150m
Yuntai
Rotation angle: horizontal 0 °～ three hundred and sixty °, Continuous rotation; Vertical-15 °～ ninety °， No occlusion in full range
Horizontal rotation speed: keying speed: 0.1 ~ 160 °/ s. Preset speed: 240 °/ s
Vertical rotation speed: keying speed: 0.1 ~ 120 °/ s. Preset speed: 200 °/ s
Pan tilt scanning: pattern scanning / limit scanning / horizontal scanning / vertical scanning / random scanning / frame scanning / panoramic scanning
Watch: preset position / Cruise track / pattern scanning / horizontal scanning / vertical scanning / random scanning / frame scanning / panoramic scanning
function
Video compression format: extra265 / h.264/mjpeg
Maximum resolution: 1920 × one thousand and eighty
Frame rate: 60 / 50 / 30 / 25FPS, settable
Multi channel coding: three bit stream
Intelligent coding: extra265 / 264
Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), Huawei SDK, Huawei rest API
Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS
Security mode: user name and password authentication, support 802.1x access authentication, and HTTPS digital certificate
Alarm linkage: alarm source: motion detection alarm / occlusion alarm / intelligent analysis alarm
Linkage target: preset position / Cruise track / scan / SD card video / SD card capture / pre recording before alarm
Media security: support SDK stream aes256 encryption
Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)
Intelligent function
Behavior analysis: items left, items removed, cross line detection, area intrusion, entry / exit area, wandering detection
Anomaly detection: image quality diagnosis, scene change detection, virtual focus detection, automatic tracking, heat map
Face & human body: traffic statistics
Vehicles: parking detection
Interface
Network interface: one RJ45 10m / 100M Ethernet port
Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card
General specifications
Power supply: AC24 V, Poe + (IEEE 802.3at)
Power consumption: maximum power consumption 25.5w, typical power consumption 12W
Working temperature: - 30 ℃ ~ 60 ℃
Working humidity: 5% - 95% (no condensation)
Lightning protection grade: 6kV
Protection grade: IP66
Weight: equipment 4.0KG, package 5.3kg
Size: equipment 310 × two hundred and one point six × 201.6, packaging 400 × two hundred and ninety-five × 295mm
