Axis f1025 sensor unit ATM ATM camera
Pinhole lens, HDTV resolution, suitable for ultra concealed indoor monitoring applications
Flexible and extremely concealed design, suitable for indoor use
Pinhole lens with 1080p resolution
92 ° wide angle horizontal field of view
WDR – forensic capture with axis F41 / f44 main unit
Highly concealed installation
Axis f1025 sensor unit (together with axis f main unit) is suitable for highly concealed indoor monitoring, such as ATM, bank, store, hotel and elevator. For example, a small axis f1025 unit can be installed in a narrow position, at the door, behind a metal plate, or embedded on a wall or ceiling, leaving only one visible pinhole for the lens.
Axis f1025 includes a 1080p resolution (1920 x 1080 pixels) image sensor and a pinhole lens that provides a 92 ° horizontal field of view.
Axis f1025 also supports wide dynamic range (WDR) – forensic capture, which can be activated when the sensor unit is connected to a host that supports this function. WDR – forensic capture can clearly present details in bright and dark scene areas.
Axis f1025 comes with a pre installed cable 3 meters or 12 meters (10 feet or 39 feet) long that can be used to connect to axis f main unit. It also comes with axis f8202 straight mounting bracket, which can be installed on a flat surface.
On the left is the image without WDR – forensic capture, and only the details of the bright area are visible. The image on the right is from axis f1025 sensor unit and axis F41 main unit with WDR – forensic capture. The details of bright and dark areas are clearly visible.
Axis F41 main unit and axis f1025 sensor unit
Learn about axis's wide dynamic range - Forensic capture's outstanding performance in backlit scenes.
Compatibility axis f main unit
AXIS F34 Main Unit
AXIS F34 Main Unit
AXIS F41 Main unit
AXIS F41 Main Unit
AXIS F44 Dual Audio Input
AXIS F44 Dual Audio Input
