Panasonic Panasonic z-thp5331lh hemisphere webcam
Panasonic Panasonic z-thp5331lh hemisphere webcam
Panasonic Panasonic z-thp5331lh hemisphere webcam
IA (Intelligent Automation) h.265 webcam
Panasonic z-thp5331lh can still obtain high-quality images in a challenging and rapidly changing monitoring environment. Using the intelligent automation (IA) scene monitoring function, the camera settings can be adjusted according to the dynamic changes of the scene and the movement of the target, so as to reduce the distortion of the real-time monitoring picture, such as the dynamic blur caused by the movement of objects. 144db dynamic range, which can also achieve clearer shooting for targets in complex light or strong backlight environment. In addition, the i-pro's 1 / 2.9 sensor makes the image quality color saturation realistic, and the color night vision function has excellent shooting performance in low illumination mode at night. Compared with H.264 image compression technology, h.265 image compression technology + Panasonic intelligent coding technology can effectively reduce the bandwidth by up to 95% *, consume less bandwidth, require less storage space and achieve longer recording time.
*Advanced mode combined with intelligent face coding technology. It varies according to the actual use environment.
High quality images can still be provided under the following challenging conditions
- automatically adjust and control the shutter speed for fast-moving vehicles.
- for pedestrians, it can provide clearer and effective images all day.
- the leading technology of true color and low noise can provide better shooting performance in low illumination environment.
- super dynamic 144db provides more applications in various complex light and strong backlight environments (including car headlights) on the streets at night.
H.265 image compression technology equipped with new intelligent coding technology
- compared with H.264 image compression technology, it consumes less bandwidth, requires less storage space and achieves longer recording time.
- the newly independently developed ROI * coding technology (automatic viqs) dynamically detects mobile areas and reduces bandwidth,
It can also ensure the clarity of motor vehicles and characters in the image.
- the new "intelligent face coding" technology improves the bandwidth utilization, and can realize higher resolution of people's faces under the condition of effective bandwidth
More clear and effective capture imaging.
*Important area of the picture
■ key features
? 1080p HD real-time images (up to 60fps)
? IA (Intelligent Automation)
? 144db ultra dynamic
? color night vision (0.0008 ~ 0.012lux)
? h.265 smart coding
Detailed specifications
video camera
image sensor
1 / 2.9 MOS image sensor
Minimum illumination
Color mode: 0.012lux, black and white mode: 0.006lux
(maximum shutter at f1.6: off (1 / 30 second), AGC: 11)
Color mode: 0.0008lux, black and white mode: 0.0004lux
(maximum shutter at f1.6: 16 / 30s, AGC: 11) * 1
white balance
AWC(2,000~10,000K)，ATW1(2,700~6,000K)，ATW2(2,000~6,000K)
shutter speed
1 / 25 fixed ~ 1 / 10000 fixed
*1 / 30 fixed shutter 2 / 120 fixed shutter is only applicable to 30fps mode
*1 / 60 fixed shutter is only applicable to 60fps mode * 1 / 25 fixed shutter 3 / 100 fixed shutter is only applicable to 25FPS mode
Intelligent automation
On / off
Super dynamic * 2
The on / off level can be set from 0 to 31
dynamic range
144db (super dynamic: on)
ABS (automatic dark area compensation)
The level can be set from 0 to 255
Backlight compensation (BLC)/
Strong light suppression (HLC)
BLC (backlight compensation) / HLC (glare suppression) / off
(only when super dynamic and intelligent automation: off)
Fog penetration compensation
On / off (only when intelligent automation is off)
AGC
The level can be set from 0 to 11
Color / black and white (infrared filter switch)
Off / on (auto 1 (normal) / Auto 2 (IR LED) / Auto 3 (SCC))
IR LED
Off / Auto (high / medium / low), irradiation distance: 30m
Digital noise reduction
The level can be set from 0 to 255
Intelligent video movement detection (i-vmd) * 3
Type 4 * software wv-sae200 to be extended
Video movement detection
On / off, 4 zones
Stabilizer * 3
On / off (30fps mode only)
Privacy area
On / off (up to 8 zones)
Image rotation * 4
0 ? / ninety ? / one hundred and eighty ? / two hundred and seventy ?
Camera caption (OSD)
On / off, up to 20 characters (letters, characters)
Focus adjustment
Auto focus / manual
camera lens
focal length
2.8~10mm
Zoom ratio
3.6x optical zoom (electric zoom / electric focus)
visual angle
[16:9 mode] horizontal: 30 ? (telescopic) ~ 110 ? (wide angle)
Vertical: 17 ? (telescopic) ~ 59 ? (wide angle)
[4:3 mode] horizontal: 25 ? (telescopic) ~ 90 ? (wide angle)
Vertical: 19 ? (telescopic) ~ 66 ? (wide angle)
Maximum aperture ratio
1: 1.6 (wide angle) ~ 1:3.4 (telescope)
Focus Range
0.3m~∞
Adjust angle
Horizontal: ± 180 ?， Vertical: ± 85 ?， Swing: ± 100 ?
browser
GUI
Camera control
Brightness, aux on / off
audio frequency
Microphone (line) input: on / off volume adjustment: low / normal / high
Audio output: on / off volume adjustment: low / normal / high
GUI / setup menu language
Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese
network
network interface
10Base-T / 100base TX, RJ45 port
Image resolution
2 megapixels [16:9] (30 / 60fps, 25 / 50FPS)
1,920 x 1,080 / 1,280 x 720 / 640 x 360 / 320 x 180
2 megapixels [16:9 & 800x600] (30fps mode)
1920 x 1080 / 1280 x 720 / 800 x 600 / 640 x 360 / 320 x 180
3 megapixel [4:3] (30fps, 25FPS)
2,048 x 1,536* / 1,280 x 960 / 800 x 600 / 640 x 480 / 400 x 300 / 320 x 240
*Using super-resolution Technology
H.265 /H.264*5
transmission mode
Fine (picture quality priority) / variable bit rate / constant rate / best effect
Transmission type
Unicast / multicast
JPEG
image quality
Level 10
Intelligent coding
Smart face code * 3: on (smart face code *) / on (automatic viqs) / off
*Smart face coding applies only to streams (1)
GOP (image group): on (Advanced) * / on (low) / on (normal) off
*On (Advanced) only for h.265
Audio compression
G.726(ADPCM) ：32kbps / 16kbps
G.711：64kbps
AAC-LC*6：64kbps / 96kbps / 128kbps
Audio transmission mode
Off / microphone (cable) input / audio output / Interactive (half duplex) / Interactive (full duplex)
Support agreement
IPv6：TCP/IP，UDP/IP，HTTP，RTP，F(xiàn)TP，SMTP，DNS，NTP，
SNMP，DHCPv6，MLD，ICMP，ARP，DiffServ
IPv4：TCP/IP，UDP/IP，HTTP，RTSP，RTP，RTP/RTCP，F(xiàn)TP，
SMTP，DHCP，DNS，DDNS，NTP，SNMP，UPnP，
IGMP，ICMP，ARP，DiffServ
Simultaneously supported clients
Up to 14 (depending on the network)
SDXC / SDHC / SD
Memory card (optional)
H. 265 / H.264 recording (supporting audio recording): manual recording / alarm recording (front / rear) / timing recording / backup in case of network failure
JPEG recording: manual recording / alarm recording (front / rear) / timing recording / backup compatible SD (SDHC / SDXC) memory card in case of network failure: Panasonic 2GB, 4GB *, 8GB *, 16GB *, 32GB *, 64GB * *, 128GB * *, 256gb * * mode * SDHC memory card * * SDXC memory card (excluding miniSD memory card and microSD memory card)
Compatible with mobile terminal
IPad, iPhone, androidtm mobile terminal
call the police
Alarm source
3 terminal inputs, VMD, command alarm, sound detection
Alarm linkage
SDXC / SDHC / SD memory card record, email notification, browser display,
FTP image transmission, Panasonic protocol output
Input/
output
Monitor output (for debugging)
VBS: 1.0V [P-P] / 75 Ω, composite signal, pin interface, NTSC / PAL signal
Audio input
? 3.5mm stereo audio interface, input impedance: About 2K Ω (unbalanced)
(applicable microphone: plug and play), power supply voltage: 2.5V ± 0.5V
Audio output
? 3.5mm stereo audio interface (mono output)
Input impedance: about 600 Ω (unbalanced)
External I / O port
Alarm input 1 (day night conversion input, automatic time adjustment) (x1),
Alarm input 2 (alarm output) (x1), alarm input 3 (x1)
General specifications
Power supply / power consumption
Power supply: DC 12V / 460ma / about 5.6W
POE (IEEE802.3 compatible) equipment: DC 48V / 125mA / about 6.0w (Level 2 equipment)
Operating ambient temperature
-10 ? C~+50 ? C
Humidity of working environment
10% ~ 90% (no condensation)
size
?129.5mm x 101mm(H)
Dome radius: 40mm
Weight (approx.)
510g
Finish
Host: ABS resin
Canvas white / ball cover part: transparent acrylic resin
■ application areas
? Airport (immigration / security / ticket office)
? shops / banks / logistics / schools / hospitals / buildings
