Bosch Bosch lbc3405 / 16 horn, 20 ", no exciter LBC 340x / 16 horn speaker
Lbc3405 / 16 horn, 20 ", without actuator
Horn, 20 inch, without actuator device, round, high-strength ABS material, suitable for use with horn actuators lbn9000 / 00 (15 W), LBN 9001 / 00 (30 W) and lbn9003 / 00 (50 W), light gray ral 7035.
Business type: lbc3405 / 16
Product No.: f.01u sixty-three point zero five one
Superior sound performance
Multiple drive unit options
Waterproof and dustproof grade shall comply with IP 65 standard
Universal mounting bracket
ultraviolet-proof
Flame retardant performance meets UL 94 V0 standard
Optional line / speaker monitoring board can be installed internally
F.01U. 063.051 lbc3405 / 16 20 "horn speaker (excluding exciter) China 641 1282
Bosch professional horn speaker system allows many different actuators to be installed in various horn speaker housings. The system consists of four horn speaker shells, three of which are circular speakers with opening diameters of 255, 380 and 510mm respectively; The other is a rectangular speaker with an opening size of 390 x 235 mm.
basic function
The exciter (ordered separately) is installed inside the horn speaker, and its connecting cable passes through the cable sealing plug on the cover plate and is connected out. This makes the speaker horn / exciter prevent liquid splashing, so it is ideal for outdoor sound reinforcement applications. Three types of exciters are available for speakers: 15 W, 30 W and 50 W (only for 100 V lines). Refer to separate data sheets. Horn speakers maximize the use of standard components of the modular concept. The screws securing the actuator are standard 1 3 / 8 inch threads (1 3 / 8 inch - 18 unef-2a). The exquisite design of the shell makes the loudspeaker unique and unique. Optional line / speaker monitoring board (and emergency connection adapter) can be installed on the inner surface of the cover plate.
In addition, the speaker is additionally equipped with an opening for loop wiring (if a loop is used, the optional cable sealing plug pg13.5 provided additionally must be used).
These loudspeakers are made of high-strength flame-retardant plastic, which is light and strong. This durable material can not only prevent ultraviolet rays, but also resist the corrosive environment and most industrial chemicals. The color of the speaker (including the bracket) is light gray. The rugged steel mounting bracket (st 37 ? 2 DIN 1652) allows users to easily install horn speakers and adjust direction.
Certificate and recognition
Waterproof and dustproof in accordance with IEC 60529, IP 65
(all models)
Flame retardant in accordance with UL 94 Vo
Product variables
Lbc3403 / 16 horn, 10 ", without actuator
Horn, 10 inch, without actuator device, round, high-strength ABS material, suitable for use with horn actuators lbn9000 / 00 (15 W), LBN 9001 / 00 (30 W) and lbn9003 / 00 (50 W), light gray ral 7035.
Business type: lbc3403 / 16
Product No.: f.01u sixty-three point zero four nine
Lbc3404 / 16 horn, 15 ", without actuator
Horn, 14 inch, without actuator device, round, high-strength ABS material, suitable for use with horn actuators lbn9000 / 00 (15 W), LBN 9001 / 00 (30 W) and lbn9003 / 00 (50 W), light gray ral 7035.
Business type: lbc3404 / 16
Product No.: f.01u sixty-three point zero five zero
Lbc3405 / 16 horn, 20 ", without actuator
Horn, 20 inch, without actuator device, round, high-strength ABS material, suitable for use with horn actuators lbn9000 / 00 (15 W), LBN 9001 / 00 (30 W) and lbn9003 / 00 (50 W), light gray ral 7035.
Business type: lbc3405 / 16
Product No.: f.01u sixty-three point zero five one
Lbc3406 / 16 horn, 8 "x15", without actuator
Horn, 15 x 9 inches, without actuator device, rectangular, high-strength ABS material, suitable for use with horn actuators lbn9000 / 00 (15 W), LBN 9001 / 00 (30 W) and lbn9003 / 00 (50 W), light gray ral 7035.
Business type: lbc3406 / 16
Product No.: f.01u sixty-three point zero five two
parts
Lbc1256 / 00 ceramic connection adapter
Emergency connection adapter, 3-pin screw ceramic connector with pre installed temperature fuse, which can be connected in series with 100 V main connection line of loudspeaker unit (100 per set).
Business type: lbc1256 / 00
Product No.: f.01u five hundred and five point nine three five
Lbn9000 / 00 horn actuator, 15W
Horn exciter, 15 W, for use with lbc3403 / 16 (10 inches), lbc3404 / 16 (14 inches), lbc3405 / 16 (20 inches) and lbc3406 / 16 (15 x 9 inches) horns.
Business type: lbn9000 / 00
Product No.: f.01u five hundred and six point zero five eight
Lbn9001 / 00 horn actuator, 30W
Horn exciter, 30 W, for use with lbc3403 / 16 (10 inches), lbc3404 / 16 (14 inches), lbc3405 / 16 (20 inches) and lbc3406 / 16 (15 x 9 inches) horns.
Business type: lbn9001 / 00
Product No.: f.01u five hundred and six point zero five nine
Lbn9003 / 00 horn actuator, 50W
Horn exciter, 50 W, for use with lbc3403 / 16 (10 inches), lbc3404 / 16 (14 inches), lbc3405 / 16 (20 inches) and lbc3406 / 16 (15 x 9 inches) horns.
Business type: lbn9003 / 00
Product No.: f.01u seven point seven zero five
