Panasonic wv-cw590 / CH, wv-cw594ch the sixth generation super dynamic outdoor day and night fastball camera
WV-CW590/CH,WV-CW594CH
Su Jie DSP processing chip, 1 / 4 CCD sensor.
Horizontal resolution 650 lines.
High sensitivity day night conversion function (infrared filter color to black) color mode low illumination 0.5Lux (f1.4, sensitivity enhancement off) black and white mode low illumination 0.04lux (f1.4, sensitivity enhancement off).
The sixth generation of super dynamic technology, dynamic range up to 160 times.
High definition image quality with 36x optical zoom lens and 20x electronic zoom lens.
Automatic tracking of moving objects.
Meet the standard of IP66 for outdoor dustproof and waterproof.
Suitable for outdoor: the sixth generation super dynamic outdoor day and night fast ball camera
Panasonic's sixth generation super dynamic outdoor day and night fastball camera is equipped with protective cover, built-in integrated pan tilt and 36x optical zoom lens, which can rotate 360 degrees. Through the use of Panasonic's unique advanced performance (such as image contrast correction based on 160 times dynamic range of each pixel), excellent image precision display is achieved. New intelligent functions include: automatic image stabilization, scene change detection and automatic tracking. Bring high reliability for outdoor monitoring. Wv-cw590 will play an active role in many security fields. It can be used to monitor parking lots, amusement parks, shopping malls, airports, railway stations, expressways, urban roads and squares.
Product features
Compared with traditional cameras, super dynamic 6 can provide 160 times wider dynamic range.
High resolution: 650 lines.
High sensitivity with day night conversion function: when f1.4 (wide angle), it is 0.5Lux in color mode and 0.04lux in black and white mode. Infrared filter (on / off) ensures enhanced sensitivity in black and white mode.
Adaptive digital noise reduction: integrated 2D / 3D digital noise reduction ensures noise reduction under various conditions.
Electronic sensitivity enhancement: automatic (up to 32 times) / manual (up to 512 times).
Electronic shutter: 1 / 120 seconds ~ 1 / 10000 seconds.
36x zoom lens: 3.3 ~ 119mm (about 720x electronic zoom).
The maximum rotation / pitch speed is 400 ° GS in preset mode and 0.065 ° GS in manual mode.
The 5 degree elevation angle makes it more applicable.
256 preset bits, which can be activated by matrix or system controller of video recorder.
Automatic tracking: the camera automatically tracks the largest moving object in the picture, and can rotate and pitch to keep the target in the center of the picture.
VMD (video motion detector) 8x6 masking area.
Scene change detection alarm: when the lens is covered, painted, moved or defocused.
4 alarm input and 2 alarm output ports.
Aarm linkage includes: port output, preset position adjustment, automatic rotation, patrol, sequence (SEQ), sorting, automatic tracking, black and white and command output.
Automatic image stabilizer can be used in vibration or strong wind.
Internal synchronization.
Coaial cable or RS485 data (Panasonic, PELCO P / D protocol) communication.
The camera caption can display up to 16 characters.
Multilingual: Chinese, English, French, Italian, Spanish, German, Russian, Japanese.
Comply with IP66 waterproof and dustproof standard. It is compatible with IEC60529 measurement standard.
Built in fan / heater for temperature change from - 50 ‰ C to + 50 ‰ C.
Built in sunshade, the camera can work in direct sunlight.
*The temperature of the working environment can reach - 50 ‰ C ~ + 50 ‰ C after assembling the optional ball cover.
