Huawei Huawei c215a-i (3.6mm) 02352vlt 5 million star level infrared tube camera
Product features
- scan CMOS with 1 / 2.7 "line by line
Support intelligent behavior analysis and audio analysis, and support metadata return
Support smooth stream, adapt to different requirements of image quality and smoothness in different scenes
Support traffic shaping, accurately control video coding burst, and ensure smooth video without losing packets
? TCP accelerates, allowing the network to carry higher-quality video stream
- embedded image quality diagnosis function
Support AES encryption of code stream and digital video watermark
Huawei Huawei c215a-i (3.6mm) image sensor: 1 / 2.7 "5 megapixel scanning CMOS line by line; maximum resolution: 2560 × 1920; Minimum Illumination: Color: 0.005lux, black and white: 0.0005lux; focal length: 3.6mm; light supplement: 30m; compression code: h.265/h.264/mjpeg; behavior analysis: support; abnormal detection: support; power supply: DC12V; working temperature: 30 ℃ ~60 ℃; protection / riot / lightning protection: IP67, 4KV; 02352vlt barrel machine 469-704 cn: c215a-i (3.6mm) 02352vlt
Product model: c215a-i (3.6mm)
video camera
Image sensor: 1 / 2.7 "5 megapixel scan CMOS line by line
Effective image size: 2560h) *1920 (V)
Minimum illumination:
Color: 0.005lux (f1.2, AGC on, 1/30 shutter)
Black and white: 0.0005lux (f1.2, AGC on, 1/30 shutter)
Day night mode: automatic (ICR) / color / black and white
Shutter speed: 1 / 3S to 1 / 68250s
Gain control: automatic / manual
Wide dynamic range: 120dB
Backlight compensation: support, optional area
White balance: automatic / manual
Strong light suppression: support
Electronic mist transmission: automatic / manual / off
Digital noise reduction: 2d/3d noise reduction
Video anti shake: support
Day and night focus compensation: support
Lens & light supplement
Focal length: 3.6mm
Maximum aperture: f1.37 (w-end) -f2.6 (t end) ± 10%
Aperture type: fixed aperture
Infrared light filling distance: 30m
function
Video compression format: h.265/h.264/mjpeg
Maximum resolution: 2560 × 1920
Frame rate: 30/25fps can be set
Video code rate: 32kbps~16mbps
Multi channel coding: three code stream
Intelligent code: extra265/264
Front end access protocol: onvif profile s/g/t, gb/t 28181 (20112016 protocol specification), Huawei SDK, Huawei rest API
Network protocol: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (v1/v2/v3), 802.1x, QoS, DDNS
Security mode: user name and password authentication, 802.1x, HTTPS security access supported
Media security: only SDK code stream aes256 encryption is supported
Video digital watermark: vulnerable digital watermark (not supported by MJPEG)
Alarm linkage: alarm source: mobile detection / occlusion / intelligent analysis, alarm linkage target: SD card video / SD card capture / pre alarm recording
Intelligent function
Behavior analysis: fast moving, items left behind, items moving away, cross-border detection, regional invasion, entry / exit area, wandering detection
Abnormal detection: image quality diagnosis, scene change detection, virtual focus detection, thermal map
Face & human body: face detection, human body detection
Vehicle: parking detection
Interface
Network interface: 1 RJ45 Ethernet port, supporting 10m/100m adaptive
Storage interface: 1 microsdhc/microsdxc card slot, maximum capacity 256gb
General specifications
Power supply: DC12V,
Power consumption: maximum power consumption 14.4w, typical power consumption 4W
Working temperature: 30 ℃ ~ 60 ℃
Working humidity: 5% - 95% (without condensation)
Lightning protection grade: 4KV
Protection level: IP67
Weight: equipment 0.59 kg, package 0.9 kg
Size: equipment 108 × 91 × 210mm, package: 296 × 141 × 117mm
