Huawei Huawei x2241-fli traffic statistics face recognition webcam 4 million superstar full color face capture barrel camera
Product features
X241 fli 4million super star full color face capture barrel camera
Scan CMOS with 1/1.8 "line by line
Full color imaging technology with black and white and color fusion
Invisible infrared without stimulation and light pollution
Built in high computational power neural network processor
Simultaneous detection and optimal capture of face, head and shoulder, human body
Support face attribute recognition and human attribute recognition
Support smooth stream, adapt to different requirements of image quality and smoothness in different scenes
Support traffic shaping, accurately control video coding burst, and video flow without losing packets
TCP accelerates, which enables the network to carry higher quality video stream
Embedded image quality diagnosis function
Product model: x241 fli
technical parameter
video camera
Image sensor: 1 / 1.8 "4mp scan CMOS line by line
Minimum illumination
Color: 0.0004lux (f1.2, AGC on, 1/30 shutter)
Black and white: 0.0001lux (f1.2, AGC on, 1/30 shutter)
Wide dynamic range: 120dB
White balance: automatic / automatic tracking / manual
Strong light suppression: support
Image fog: Auto / manual / off
Digital noise reduction: 2d/3d noise reduction
Day and night mode: automatic (ICR) / color / super star full color
Lens & fill
Focal length: 12-55mm
Maximum aperture: f1.35
Aperture type: p-iris
Light filling distance: 30m, no perception to naked eye
function
Video compression format: h.265/h.264/mjpeg
Maximum resolution: 2560 × 1440
Frame rate: 30/25fps
Multi channel coding: five stream, supporting up to 4million independent HD coding
Intelligent code: extra265/264
Front end access protocol: onvif profile s/g/t, gb/t 28181 (20112016 protocol specification), gb35114-2017, Huawei SDK, Huawei rest API
Network protocol: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (v1/v2/v3), 802.1x, QoS, DDNS, SMTP
Security mode: user name and password authentication, 802.1x, HTTPS security access supported
Media security: support encryption of SDK code stream aes256
Alarm linkage: alarm source: mobile detection alarm / occlusion alarm / switch input / intelligent analysis alarm linkage: switch output / SD card video / SD card capture / email sending / pre record before alarm
Intelligent analysis
Personnel detection: support simultaneous detection and optimal capture of face, head and shoulder, human body.
Personnel attribute analysis: whether to wear masks and other 5 human attributes, gender, age, clothing style and other 7 human attributes, support the analysis of pedestrian riding attributes.
Personnel behavior analysis: fast moving, items left behind, items moving away, cross-line detection, regional invasion, entering / leaving the area, wandering detection.
Abnormal detection: image quality diagnosis, virtual focus detection, audio presence or not, audio steep rise and fall, scene change detection, heat map, personnel gathering.
Crowd situation analysis: regional statistics, traffic statistics, queue length.
Interface
Network interface: 2 RJ45 10m/100m/1000m adaptive Ethernet ports
Communication serial port: 1 RS-485 interface
Alarm interface: 2-way alarm input and 1-way alarm output
Audio interface: 1 way audio input and 1 channel audio output
Storage interface: 1 microsdhc/microsdxc card slot, maximum capacity 256gb
General specifications
Power supply: AC24V
Power consumption: maximum power consumption 32W, typical power consumption 8.5W
Working temperature: 40 ℃ ~60 ℃
Working humidity: 5% - 95% (without condensation)
Lightning protection grade: 6kV
Protection grade: IP66
Weight: 2.36kg of equipment, 3.3kg package
Dimensions: equipment 129 * 106 * 292.5mm; package 533 * 259 * 146mm
Appearance size
Unit: mm
