Huawei Huawei c662a-z23-sf 02352vfw 2 million star level infrared ball camera
Product features
- support extra265 encoding format, support two-way independent 1080p HD coding
? 1080p@60fps High frame rate, smoother video image
- strong light suppression, no key information lost under strong light interference
- 120dB super wide dynamic, strong contrast scene real restore details
Intelligent fog penetration, enhance image clarity in fog scene
- Metadata intelligent extraction, providing massive metadata for Intelligent Applications
- code flow package, typical scenario configuration package and planning tasks
- sec super error correction, 20% network packet loss image is still smooth
Active automatic demisting to prevent fog from rising inside the shield
- fast installation structure, more efficient installation and deployment
Huawai c662a-z23-sf image sensor: 1 / 2.7 "2 megapixel scanning CMOS; maximum resolution: 1920 × 1080; Minimum Illumination: Color: 0.005lux, black and white: 0.0005lux; focal length: 5-115mm; optical zoom ratio: 23; horizontal rotation range: 0 ° ~ 360 °; vertical rotation range: 15 ° ~ 90 °; light supplement: 150m; compression code: h.265/h.264/mjpeg; behavior analysis: support; abnormal detection: support; Intelligent tracking: support; power supply: AC24V, poe+ (IEEE 802.3at); working temperature: 30 ℃ ~60 ℃; protection / riot / lightning protection: IP66, 6kV; 02352vfw fast ball 1737-2606 CN: c662a-z23-sf 02352vfw
technical parameter
Product model: c662a-z23-sf
video camera
Image sensor: 1 / 2.7 "2 megapixel scan CMOS line by line
Effective image size: 1920 (H) × 1080 (V)
Minimum illumination:
Color: 0.005lux (f1.2, AGC on, 1 / 30 shutter)
Black and white: 0.0005lux (f1.2, AGC on, 1 / 30 shutter)
Day night mode: automatic (ICR) / color / black and white
Shutter speed: 1 / 3S ~ 1 / 68250s
Wide dynamic range: 120dB
Gain control: automatic / manual
White balance: automatic tracking / automatic / manual
Strong light suppression: support
Image fog: Auto / manual / off
Video anti shake: support
Day and night focus compensation: support
Lens & fill
Focal length: 5-115mm
Doubling: 23 times optical, 16 times digital
Maximum aperture: f1.55
Aperture type: p-iris
Light compensation distance: 150m
Yuntai
Rotation angle: horizontal 0 ° ~ 360 °, continuous rotation; vertical-15 ° ~ 90 °, no occlusion in the whole range
Horizontal rotation speed: keying speed: 0.1 ~ 160 ° / s, preset speed: 240 ° / s
Vertical rotation speed: keying speed: 0.1 ~ 120 ° / s, preset speed: 200 ° / s
Cloud scanning: pattern scan / limit scan / horizontal scan / vertical scan / random scan / frame scan / panoramic scanning
Watch: preset position / Cruise track / pattern scan / horizontal scan / vertical scan / random scan / frame scan / panoramic scan
function
Video compression format: extra265/h.264/mjpeg
Maximum resolution: 1920 × 1080
Frame rate: 60 / 50 / 30 / 25FPS, settable
Multi channel coding: three bit stream
Intelligent coding: extra265 / 264
Front end access protocol: onvif profile s/g/t, gb/t 28181 (20112016 protocol specification), GB 35114-2017, Huawei SDK, Huawei rest API
Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS
Security mode: user name and password authentication, 802.1x access authentication, HTTPS digital certificate
Alarm linkage: alarm source: mobile detection alarm / occlusion alarm / intelligent analysis alarm
Linkage target: preset position / Cruise track / scan / SD card video / SD card capture / pre recording before alarm
Media security: support encryption of SDK code stream aes256
Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)
Intelligent function
Behavior analysis: fast move detection, legacy detection, move away detection, over line detection, intrusion detection, area entry / exit area detection, wandering detection
Anomaly detection: scene change detection, virtual focus detection, heat map, personnel gathering
Vehicles: parking detection
Intelligent tracking: Panoramic automatic tracking, event linkage tracking, manual tracking
Interface
Network interface: 1 RJ45 10m/100m Ethernet port
Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card
General specifications
Power supply: AC24 V, Poe + (IEEE 802.3at)
Power consumption: maximum power consumption 23W, typical power consumption 9.5W
Working temperature: 30 ℃ ~60 ℃
Working humidity: 5% ~ 95% (no condensation)
Lightning protection grade: 6kV
Protection grade: IP66
Weight: equipment 4.0KG, package 5.3kg
Size: equipment 310 × 201.6 × 201.6, package 400 × 295 × 295mm
