Panasonic z-thp5331lh IA (Intelligent Automation) h.265 network camera z-thp5331lh
IA (Intelligent Automation) h.265 network camera
Z-THP5331LH
IA (Intelligent Automation) h.265 network camera
Panasonic z-thp5331lh can still obtain high-quality images in a challenging and rapidly changing monitoring environment. With the function of Intelligent Automation (IA) scene monitoring, the camera settings can be adjusted according to the dynamic changes of the scene and the movement of the target, so as to reduce the distortion of the real-time monitoring picture, such as the dynamic blur caused by the moving of objects. 144db dynamic range, can be complex light or backlight strong environment of the target, also achieve more clear shooting. In addition, i-pro's 1/2.9 sensor makes the color saturation of painting vivid, and the color night vision function has excellent shooting performance in low illumination mode at night. Compared with H.264 image compression technology, h.265 image compression technology + Panasonic intelligent coding technology can effectively reduce the bandwidth up to 95% *, consume less bandwidth, require less storage space, and achieve longer recording time.
*Advanced mode combined with intelligent face coding technology. It varies according to the actual use environment.
High quality images are still available under the following challenging conditions
- for fast moving vehicles, automatically adjust and control the shutter speed.
- provide clear and effective images for pedestrians all day long.
- the leading technology of true color and low noise can provide better shooting performance in low illumination environment.
- super dynamic 144db provides more applications in the night streets in a variety of complex lighting and backlight environments, including car headlights.
H.265 image compression technology with new intelligent coding technology
- compared with H.264 image compression technology, it consumes less bandwidth, requires less storage space and achieves longer recording.
- a new independent roi* coding technology (automatic viqs), which dynamically detects mobile areas, while reducing bandwidth,
It also ensures the clarity of motor vehicles and characters in images.
- the new "intelligent face coding" technology improves the bandwidth utilization, and can achieve higher resolution for the face of the character under the effective bandwidth condition
More clear and effective capture imaging.
*Important areas of the picture
■ key features
1080p high definition real-time image (up to 60fps)
? IA (Intelligent Automation)
144db super dynamic
Color night vision (0.0008-0.012lux)
H.265 intelligent coding
■ application area
Airport (immigration / security check-out / ticket office)
Store / bank / logistics / school / hospital / building
■ appearance
■ installation drawing
Trademarks and registered trademarks
- iPad, iPhone is a trademark registered by apple.
- Android is a trademark of Google Inc.
- nvif and onivf logo are trademarks of onvif.
- all other trademarks above belong to their respective owners.
important
- safety precautions: please read the relevant operation manual and installation manual carefully before using this product.
- Panasonic is not responsible for network performance and / or problems with the product on the network.
■ options
Insertion software for mobile video detection
WV-SAE200
I-vmd detects objects in specific areas through advanced video analysis technology.
I-vmd: intrusion detection, hover detection, direction detection, scene change detection, target detection, over line detection
·Approximate weight and size. Specification change without notice
video camera image sensor MOS image sensor type 1/2.9
Minimum illumination Color mode: 0.012lux, black and white mode: 0.006lux
(maximum shutter at f1.6: off (1/30 seconds), agc:11)
Color mode: 0.0008lux, black and white mode: 0.0004lux
(maximum shutter at f1.6: 16/30 seconds max, agc:11) *1
white balance AWC(2,000~10,000K)，ATW1(2,700~6,000K)，ATW2(2,000~6,000K)
shutter speed 1 / 25 fixed to 1 / 10000 fixed
*1 / 30 fixed shutter 2 / 120 fixed shutter only for 30fps mode
*1 / 60 fixed shutter only for 60fps mode *1/25 fixed shutter 3/100 fixed shutter only for 25FPS mode
Intelligent automation On / off
Super dynamic *2 The setting range of on / off level is: 0-31
dynamic range 144db (super dynamic: on)
ABS (automatic dark area compensation) The level can be set as: 0-255
Backlight compensation (BLC)/
Strong light suppression (HLC) BLC (backlight compensation) / HLC (strong light suppression) / off
(only in super dynamic and intelligent automation: off)
Fog leakage compensation On / off (only in Intelligent Automation: off)
AGC The level can be set as: 0-11
Color / black and white (infrared filter switcher) Off / on (automatic 1 (normal) / automatic 2 (IR LED) / automatic 3 (SCC))
IR LED Off / Auto (high / medium / low), irradiation distance: 30m
Digital noise reduction The level can be set as: 0-255
Intelligent video mobile detection (i-vmd) *3 Type 4 * software wv-sae200 to be extended
Video mobile detection On / off, 4 areas
Stabilizer *3 On / off (only for 30fps mode)
Privacy zone On / off (up to 8 areas)
Image rotation *4 0 ? / ninety ? / one hundred and eighty ? / two hundred and seventy ? Camera subtitle (OSD) On / off, up to 20 characters (letters, characters)
Focus adjustment Auto rear focus / manual
camera lens focal length 2.8~10mm
Variable coke ratio 3.6 times optical zoom (electric zoom / electric focus)
visual angle [ 16: 9 mode] level: 30 ?( Far away) ~110 ?( Wide angle)
Vertical: 17 ?( Far away) ~59 ?( Wide angle)
[4:3 mode] level: 25 ?( Far away) ~90 ?( Wide angle)
Vertical: 19 ?( Far away) ~66 ?( Wide angle)
Maximum aperture ratio 1: 1.6 (wide angle) ~1:3.4 (far sighted)
Focus Range 0.3m~∞
Adjust the angle Level: ± one hundred and eighty ?， Vertical: ± eighty-five ?， Swing: ± one hundred ? browser
GUI Camera control Brightness, aux on / off
audio frequency Microphone (line) input: on / off volume adjustment: low / normal / high
Audio output: on / off volume adjustment: low / normal / high
GUI / setup menu language Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese
network network interface 10Base-T / 100base TX, RJ45 port
Image resolution 2 megapixel [16:9] (30/60fps, 25/50fps)
1,920 x 1,080 / 1,280 x 720 / 640 x 360 / 320 x 180
2 megapixel [16:9 & 800x600] (30fps mode)
1920 x 1080 / 1280 x 720 / 800 x 600 / 640 x 360 / 320 x 180
3 megapixel [4:3] (30fps, 25FPS)
2,048 x 1,536* / 1,280 x 960 / 800 x 600 / 640 x 480 / 400 x 300 / 320 x 240
*Using super-resolution Technology
H.265 /H.264*5 transmission mode Fine (picture quality priority) / variable bit rate / constant rate / best effect
Transmission type Unicast / multicast
JPEG image quality Grade 10
Intelligent coding Smart face code *3: on (smart face code *) / on (automatic viqs) / off
*Smart face coding only for streams (1)
GOP (image group): on (Advanced) * / on (low) / on (normal) off
*On (Advanced) only for h.265
Audio compression G.726(ADPCM) ：32kbps / 16kbps
G.711：64kbps
AAC-LC*6：64kbps / 96kbps / 128kbps
Audio transmission mode Off / microphone (connector) I / audio out / Interactive (half duplex) / Interactive (full duplex)
Support agreement IPv6：TCP/IP，UDP/IP，HTTP，RTP，F(xiàn)TP，SMTP，DNS，NTP，
SNMP，DHCPv6，MLD，ICMP，ARP，DiffServ
IPv4：TCP/IP，UDP/IP，HTTP，RTSP，RTP，RTP/RTCP，F(xiàn)TP，
SMTP，DHCP，DNS，DDNS，NTP，SNMP，UPnP，
IGMP，ICMP，ARP，DiffServ
Clients supported at the same time Up to 14 (depending on the network)
SDXC / SDHC / SD
Memory card (optional) H. 265 / H.264 record (audio recording supported): manual record / alarm record (front / rear) / timing record / backup in case of network failure
JPEG record: manual record / alarm record (front / rear) / timing record / backup compatible SD (sdhc/sdxc) memory card in case of network failure: Panasonic 2GB, 4gb*, 8gb*, 16gb*, 32gb*, 64gb*, 128gb*, 256gb * * mode * SDHC memory card * *sdxc memory card (excluding miniSD memory card and microSD memory card)
Mobile terminal compatible IPad, iPhone, androidtm mobile terminal
call the police Alarm source 3 terminal inputs, VMD, command alarm, sound detection
Alarm linkage SDXC / SDHC / SD memory card record, email notification, browser display,
FTP image transmission, Panasonic protocol output
Input/
output Monitor output (for debugging) VBS：1.0V[p-p] / 75 Ω ， Composite signal, pin interface, NTSC / PAL signal
Audio input ? 3.5mm stereo audio interface, input impedance: About 2K Ω( Imbalance)
(applicable microphone: plug and play type), power supply voltage: 2.5V ± 0.5V
Audio output ? 3.5mm stereo audio interface (mono output)
Input impedance: about 600 Ω( Imbalance)
External I / O port Alarm input 1 (day night conversion input, time auto adjustment) (x1),
Alarm input 2 (alarm output) (x1), alarm input 3 (x1)
General specifications Power / power consumption Power supply: DC 12V / 460ma / about 5.6W
POE (IEEE802.3 compatible) device: DC 48V / 125mA / about 6.0w (Level 2 device)
Working environment temperature - ten ? C~+50 ? C
Working environment humidity 10% - 90% (no condensation)
size ? 129.5mm x 101mm(H)
Dome radius: 40mm
Weight (approximately) 510g
Finish Main engine: ABS resin
Canvas white / ball cover: transparent acrylic
*1 conversion value.
*2. Super dynamic function is automatically turned off in 60fps mode.
*3 stabilizer, intelligent face coding technology, i-vmd function can not be used at the same time.
*4 when "3 megapixel [4:3] (30fps mode) is selected under" image capture mode ", the" 90 "cannot be selected simultaneously ?” And "270" ?”。 * 5. The four stream transmission can be separately set in the same compression method.
*6 aac-lc (enhanced audio coding - low complexity) is only used when recording audio with SD memory card.
