Bosch Bosch nn-50022-v3 HD network hemispheric camera f.01u.273.888



NIN-50022-V3

F.01U.273.888

IP dome camera 1080p indoor

1080p resolution, clear image available

Use auto zoom / focus lens, setup wizard, pre configuration mode, etc

Features, easier installation

Fully configurable four code streams

Interest zone and e-ptz

Bosch HD indoor ball camera is a professional monitoring camera, which can provide high-quality high-definition images to meet the requirements of strict security and monitoring network. These ball cameras are real day / night cameras that offer excellent performance during the day or night. One version is equipped with an internal active infrared light that provides extremely high light

Excellent performance in weak environments. The system overview is easy to install the fashionable indoor ball camera fashion design suitable for the installation occasions that pay attention to the appearance and flexible coverage area, is an ideal choice for indoor use. Zoom lens allows you to select coverage areas for your application. By using proprietary cloud platform devices, the installer can select exactly the monitoring area needed. There are many options for installation, including surface mounting, wall mounting and ceiling installation. The autozoom / focus lens wizard allows the installer to ensure accurate zoom and focus effects both during the day and night. The wizard can be activated by PC or by on-board camera button, which makes it easy to select workflow flexibly. The AVF function means that the camera is not required to be turned on to zoom. Automatic electric zoom / focus adjustment with 1:1 pixel mapping ensures that the camera is always focused accurately.

sensor 1 / 2.7 "CMOS

Effective pixel 1920 x 1080

Day night conversion Mechanical filter

video compression H.264 MP,M-JPEG,

data stream Four video streams that can be configured separately

Maximum resolution 1080p

Minimum illuminance (color) 0.3lux

Minimum illumination (black and white) 0.1lux

dynamic range 69dB

Intelligent noise reduction (idnr) support

Intelligent auto exposure (IAE) -

Video mobile detection Motion+

Intelligent video analysis (IVA) -

Privacy masking 4 programmable areas

Interest area Two ROI interest areas

SD card storage Microsdxc card, 2TB maximum

Analog video output Analog composite (service)

Triaxial support support

camera lens 3 to 10 mm

F1.3 to close

Lens adjustment -

Audio input Built in microphone or line in

Audio output Line output

wireless -

Wireless security -

PoE IEEE 802.3at compliant

Power Supply 12 VDC or Poe

power waste 4.5 W

Dimensions (diameter x height) 135 x 102 mm

weight 554 G

Protection level -

Impact protection -

Night viewing distance -

Red light LED -

vehicle -

Onvif standard support
