Fujineng Fujinon hd60x12.5r3de-v21 day and night fog penetration electric zoom lens 12.5-750mm
Fujineng Fujinon hd60x12.5r3de-v21 day and night fog penetration electric zoom lens 12.5-750mm
Fujineng Fujinon hd60x12.5r3de-v21 day and night fog penetration electric zoom lens 12.5-750mm
|
Vari-Focal |
|
Wide Angle |
|
Telephoto Long Focal |
|
Day & Night |
|
DC Auto Iris |
|
CS Mount |
|
Metal Mount |
|
ND Filter |
|
Long Cable |
|
Aspherical Lens |
|
Wide Aperture Rate |
Specification 1 / 1.8 "
Interface C
Focal length 12.5 ~ 750mm 25 ~ 1500mm (2x)
Aperture range f3.6 ~ F16. C
The near infrared wavelength is 808mm, 850mm and 950mm
Operation mode
Zoom electric
Focusing electric
Aperture DC automatic, video automatic or remote control
visual angle
（HXV）
1/8＂
Wide angle end 32 ° 10 ′ x 24 ° 18 ′ 16 ° 05 ′ x 12 ° 09 ′ (2x)
Telephoto end 0 ° 34 ′ x 0 ° 25 ′ 0 ° 17 ′ x 0 ° 13 ′ (2x)
1/2＂
Wide angle end 28 ° 43 ′ x 21 ° 44 ′ 14 ° 35 ′ x 10 ° 58 ′ (2x)
Telephoto end 0 ° 29 ′ x 0 ° 22 ′ 0 ° 15 ′ x 0 ° 11 ′ (2x)
Minimum object distance (M. O. D.) 5m
Object size at minimum object distance
（HXV）
1/8＂
Wide angle end 2595x1989mm 1298x995mm (2x)
Long focal end 58x38mm 29x19mm (2x)
1/2＂
Wide angle end 1929x1110mm 972x553mm (2x)
Long focal end 34x20mm 17x10mm (2x)
Rear focal length (air converted length) 53.23mm
Exit pupil (from imaging surface) - 77 / - 38mm (2x)
Color filter diameter m107x1mm
Weight 5.2kg
(H x W x L) 137x154x354mm
Remarks metal interface
