Axis p3707-pe webcam
Flexible 360 degree multi-sensor camera
8 megapixel 360 degree multisensor camera with one IP address
Four zoom camera head with flexible positioning
1080p video with frame rate of 12.5/15 FPS; 720p video with frame rate of 25 / 30 FPS; Quad split screen
Axis zipstream Technology
Ethernet power supply
Outdoor special
AXIS P3707-PE Network Camera
AXIS P3707-PE Network Camera
AXIS P3707-PE Network Camera
Panorama and close-up
Axis p3707-pe webcam obtains 360 degree panorama or combination of panorama and close-up. The 8 megapixel multi-sensor fixed camera has four zoom camera heads, which can capture the scene from all directions with a wide viewing angle or enlarged viewing angle.
Axis p3707-pe is essentially a four camera integrated device, which can provide cost-effective solutions for monitoring large indoor and outdoor areas, such as retail stores, shopping centers, warehouses, school lounges, hotel lounges, office lounges and parking lots. It is also very suitable for the intersection of lobby, aisle and road and the corner of buildings.
Cost savings
Because the four camera heads are placed in one main body, axis p3707-pe is very cost-effective, and its price and performance are comparable to the four standard zoom cameras. Installation is much easier because only one rather than four network cables are required. One cable also reduces the number of ports required on the switch. The camera has an IP address, which means that for most video management systems, it only needs one software license fee (not four). In addition, the camera is powered by Ethernet, so there is no need to connect to a nearby power outlet. Axis p3707-pe also has low power consumption, with a maximum power of 5.5 W.
Reducing the bit rate with Axis Zipstream
Axis zipstream
The camera supports axis zipstream technology, which is very beneficial when using 8 megapixel streaming video. Zipstream can realize more efficient implementation of H.264 video encoder. It is suitable for a variety of monitoring scenarios and can reduce bandwidth and storage requirements by more than 50% on average. Coding technology ensures that important details are retained when unnecessary data is over compressed.
Flexible installation
The installer can optimize the field of vision through each zoom lens of axis p3707-pe to meet the monitoring requirements: wide angle is suitable for panoramic monitoring, and long focus is suitable for enlarged pictures requiring clearer details. For optimal positioning, each camera head can slide flexibly + / - 90 ° along the circular track. Each camera head can also be tilted 28 ° to 92 °. In order to capture vertical scenes (such as long corridors and roads), each camera head can be rotated 90 ° to support axis corridor format.
P3707-PE Corridor Coverage
Rotatable camera heads: (A) Line vertically positioned for 9:16 Axis’ Corridor Format for coverage of vertically oriented scenes such as hallways. (B) Horizontal position for standard 16:9 views.
P3707-PE 360 Coverage
Under the cover: The four camera heads of AXIS P3707-PE can together cover a 360° area, with each having a 108° horizontal field of view at max. wide and 54° at max. telephoto. (A) One RJ45 connector for the network cable. (B) Built-in microSD card slot.
The camera heads can be repositioned to fully cover the more than 270° area from the outer corner of a building.
Movable heads: The camera heads can be repositioned to fully cover the more than 270° area from the outer corner of a building.
P3707-PE Corridor Coverage
Rotatable camera heads: (A) Line vertically positioned for 9:16 Axis’ Corridor Format for coverage of vertically oriented scenes such as hallways. (B) Horizontal position for standard 16:9 views.
P3707-PE 360 Coverage
Under the cover: The four camera heads of AXIS P3707-PE can together cover a 360° area, with each having a 108° horizontal field of view at max. wide and 54° at max. telephoto. (A) One RJ45 connector for the network cable. (B) Built-in microSD card slot.
one
two
three
Two capture modes
AXIS P3707-PE uses Axis’ Corridor Format to capture vertically oriented scenes in four different directions
Axis p3707-pe uses axis corridor mode to capture vertical scenes from four directions
With axis p3707-pe, you can set the video viewfinder mode separately for each camera head, so that you can optimize the resolution or frame rate of four scenes respectively. The viewfinder mode determines the maximum resolution and frame rate to stream.
The 1080p viewfinder mode achieves a maximum resolution of 1920 x 1080 pixels and a maximum frame rate of 12.5/15 frames per second (50 / 60 Hz). It also supports a 108 ° horizontal field of view when the camera lens is in the widest position. At the maximum telephoto position, it has a horizontal field of view of 54 °.
720p viewfinder mode can achieve a maximum resolution of 1280 x 720 pixels and a maximum frame rate of 25 / 30 frames per second (50 / 60 Hz). When the camera lens is at the widest position, the 720p mode can achieve a horizontal field of view of 67 ° and a horizontal field of view of 36 ° at the maximum zoom position.
The camera supports four split pictures, which is a video stream captured and displayed synchronously in four quadrants through four camera heads.
High video quality
The axis p3707-pe camera is equipped with a specially designed transparent cover with smooth edges. This ensures that the picture in all directions is clear without distortion. With the help of four 1080p image sensors with a total of 8 million pixels, the pictures of all four scenes can maintain high image quality. The camera also has good low light level shooting performance and can provide color video under low light level conditions of 0.3 lux.
AXIS P3707-PE Network Camera
Outdoor special
Axis p3707-pe has IP66 and NEMA 4x protection, which can prevent dust, rain, snow, ice and corrosion. The camera can be installed indoors or outdoors, and its operating temperature range is - 30 ° C to 60 ° C (- 22 ° f to 149 ° f). It also has ik09 impact resistance, which can prevent damage.
Axis-p3707 is installed on the ceiling and attached to the ceiling. Using axis t94m02d suspension kit and most axis T91 installation accessories, the camera can also be installed in corners of buildings or on poles and railings. The suspension kit provides weather protection cover and mounting adapter. The kit and axis T91 accessories are sold separately.
