Huawei m214d-ebi (3.6mm) 02352rkm (3.6mm / 6mm) 4 million b
ehavior analysis cylindrical camera
Product features
1 / 2.7 "progressive scan CMOS
Support stream smoothing, adapt to different requirements of image quality and fluency in different scenes
Support traffic shaping, accurately control video coding instant burst, smooth video without packet loss
TCP acceleration enables the network to carry higher quality video stream
Embedded image quality diagnosis function
Support stream AES encryption
Huawei m214d-ebi (3.6mm) image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS; maximum resolution: 2560 × 1440; Minimum Illumination: Color: 0.015lux, black and white: 0.0075lux; focal length: 3.6mm; fill light: 50m; compression coding: h.265/h.264/mjpeg; behavior analysis: support; anomaly detection: support; queue length detection: support; crowd density detection: support; power supply: DC12V; working temperature: - 30 ℃ ~ 60 ℃; Protection / riot / lightning protection: IP66, 4KV; 02352rkm cylinder machine 625-938 CN: m214d-ebi (3.6mm) 02352rkm
technical parameter
Product model: m214d-ebi (3.6mm / 6mm)
video camera
Image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS
Effective image size: 2560 (H) * 1920 (V)
Minimum illumination:
Color: 0.015lux (f1.2, AGC on, 1 / 30 shutter)
Black and white: 0.0075lux (f1.2, AGC on, 1 / 30 shutter)
Day and night mode: ICR / color / black and white
Shutter speed: 1 / 3S ~ 1 / 68250s
Wide dynamic range: 120dB
White balance: Auto / auto tracking / manual
Strong light suppression: support
Image fogging: Auto / manual / off
Digital noise reduction: 2D / 3D noise reduction
Video anti shake: support
Lens & fill
Focal length: 3.6mm/6mm
Maximum aperture: f1.6
Aperture type: fixed aperture
Lighting distance: 50m
function
Video compression format: h.265/h.264/mjpeg
Maximum resolution: 2560 × 1440
Frame rate: 30 / 25FPS
Multi channel coding: three bit stream, support 1080p dual independent HD coding
Bitstream package: built in: high quality / balanced / low bandwidth / low pixel basic bitstream package
Intelligent coding: extra265 / 264
Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), Huawei SDK, Huawei rest API
Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS, SMTP
Security mode: user name and password authentication, support 802.1x, HTTPS security access
Media security: only support SDK stream aes256 encryption
Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)
Alarm linkage: alarm source: mobile detection alarm / occlusion alarm / intelligent analysis alarm; linkage: SD card video / SD card capture / email sending / pre recording before alarm
Intelligent analysis
Behavior analysis: fast mobile detection, legacy detection, move detection, cross line detection, intrusion detection, zone in / out zone detection, wandering detection
Anomaly detection: image quality diagnosis, virtual focus detection, scene change detection, heat map
Crowd situation analysis: queue length, regional number of people statistics, traffic statistics
Interface
Network interface: one RJ45 10m / 100M adaptive Ethernet port
Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card
General specifications
Power supply: DC12V
Power consumption: maximum power consumption 7W, typical power consumption 5W
Working temperature: - 30 ℃ ~ 60 ℃
Working humidity: 5% ~ 95% (non condensing)
Lightning protection grade: 4KV
Protection grade: IP66
Weight: equipment 0.59kg, package 0.9kg
Size: equipment 108 * 91 * 210mm; package 296 * 141 * 117mm
