Huawei m214d-evl (7-35mm) 02352rkl 4 million vehicle identification barrel camera
Product features
1 / 2.7 "progressive scan CMOS
Support region clipping, limited bandwidth, see local details clearly
Support stream smoothing, adapt to different requirements of image quality and fluency in different scenes
Support traffic shaping, accurately control video coding instant burst, smooth video without packet loss
TCP acceleration enables the network to carry higher quality video stream
Embedded image quality diagnosis function
Support stream AES encryption
Huawei m214d-evl (7-35mm) image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS; maximum resolution: 2560 × 1440; Minimum Illumination: Color: 0.015lux, black and white: 0.0075lux; focal length: 7-35mm; fill light: 20m; compression coding: h.265/h.264/mjpeg; behavior analysis: support; anomaly detection: support; machine non human classification: support; vehicle recognition: support; power supply: DC12V, Poe + (IEEE 802.3at); Working temperature: - 30 ℃ ~ 60 ℃; protection / riot / lightning protection: IP66, 4KV; 02352rkl cylinder 1220-1830 CN: m214d-evl (7-35mm) 02352rkl
technical parameter
Product model: m214d-evl (7-35mm)
video camera
Image sensor: 1 / 2.7 "4 megapixel progressive scan CMOS
Effective image size: 2560 (H) * 1920 (V)
Minimum illumination:
Color: 0.005lux (f1.2, AGC on, 1 / 30 shutter)
Black and white: 0.0025lux (f1.2, AGC on, 1 / 30 shutter)
Day and night mode: ICR / color / black and white
Shutter speed: 1 / 3S ~ 1 / 68250s
Wide dynamic range: 120dB
White balance: Auto / auto tracking / manual
Strong light suppression: support
Image fogging: Auto / manual / off
Digital noise reduction: 2D / 3D noise reduction
Video anti shake: support
Day and night focus compensation: support
Lens & fill
Focal length: 7-35mm
Maximum aperture: f1.4
Aperture type: p-iris
Light compensation distance: 20m
function
Video compression format: h.265/h.264/mjpeg
Maximum resolution: 2560 × 1440
Frame rate: 30 / 25FPS
Multi channel coding: three bit stream, support 1080p dual independent HD coding
Region clipping coding: only sub stream one support
Intelligent coding: extra265 / 264
Front end access protocol: onvif profile s / g / T, GB / T 28181 (20112016 protocol specification), Huawei SDK, Huawei rest API
Network protocols: TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, sip, ARP, SSL, NTP, SNMP (V1 / V2 / V3), 802.1x, QoS, DDNS, SMTP
Security mode: user name and password authentication, support 802.1x, HTTPS security access
Media security: only support SDK stream aes256 encryption
Video Digital Watermarking: support fragile digital watermarking (MJPEG does not support)
Alarm linkage: alarm source: motion detection alarm / occlusion alarm / intelligent analysis alarm
Linkage: SD card video / SD card capture / email sending / pre recording before police
Intelligent analysis
Behavior analysis: fast mobile detection, legacy detection, move detection, cross line detection, intrusion detection, zone in / out zone detection, wandering detection
Anomaly detection: image quality diagnosis, virtual focus detection, scene change detection, heat map
Vehicle: license plate recognition, body color, vehicle model, vehicle type, vehicle incident, motor vehicle occupying non motor vehicle lane, non motor vehicle occupying motor vehicle lane, illegal parking, line pressing, retrograde / reverse, abnormal license plate, traffic parameter collection
Machine non human: machine non human structure
Interface
Network interface: one RJ45 10m / 100M adaptive Ethernet port
Storage interface: provide microSD card slot, support microSDHC / microsdxc, support 256gb maximum capacity memory card
General specifications
Power supply: DC12V, Poe (IEEE 802.3at)
Power consumption: maximum power consumption 18W, typical power consumption 8W
Working temperature: - 30 ℃ ~ 60 ℃
Working humidity: 5% ~ 95% (non condensing)
Lightning protection grade: 4KV
Protection grade: IP66
Weight: equipment 0.94kg, package 1.24kg
Size: equipment 108 * 91 * 210mm; package 296 * 141 * 117mm
Recommended accessories
Wall bracket: dts-12c
Column support: dts-11c
Universal joint: dts-13c
Indoor hoisting: dts-07h
DC12V power adapter: eadapte09
